Ubiquiti Networks 60W PoE++ Adapter, RJ45 Shielded Socket, IEC-320 C6 AC Connector, High-Power PoE Injector for UniFi Devices, Compact Design, White

140,00 AED

Send Enquiry On Whatsapp
Add to Enquiry
  • Delivers up to 60W of PoE++
  • Surge, peak pulse, and overcurrent protection
  • Contains RJ45 data input, AC cable with earth ground, and PoE++ output
  • LED indicator for status monitoring
Overview
Dimensions 106 x 63 x 34 mm (4.2 x 2.5 x 1.3")
Weight 210 g (7.4 oz)
Output Voltage 48V DC at 1.25A
Rated Voltage 100—240V AC at 50/60Hz
Gigabit LAN Port ✓
4-pair Powering Pins 1, 2, 4, 5 (+) and 3, 6, 7, 8 (-)
AC Connector IEC-320 C6
Clamping Protection 11V Data, 60V Power
Data In / PoE RJ45 Shielded Socket
Input Current 1.3A @ 120V AC
Inrush Current
Efficiency 85+%
Switching Frequency 65 kHz
Output Ripple 1% Max.
Line Regulation ≤ 1%
Load Regulation ≤ 3%
Max. PoE+ Wattage 60W per port by PSE
Max. Surge Discharge 1500A (8/20 μs) power
Peak Pulse Current 36A (10/1000 μs) data
Power Method Universal AC input, 100—240V AC, 50/60 Hz
Power Supply AC/DC
Response Time
Shunt Capacitance
Supported Voltage Range 100—240V AC
Surge Protection Difference and common mode
Storage Temperature -30 to 70°C (-22 to 158° F)
Operating Temperature 0 to 40° C (32 to 104° F)
Operating Humidity 10 to 95% noncondensing
NDAA Compliant ✓
Certifications CE, FCC, IC, UL, UKCA, KC, CCC, RoHS
