Silverstone Triton 750Rx Non Modular Power Supply, 750W Power, Cybenetics Gold Efficiency, Active PFC, Japanese Electrolytic Capacitors, 120mm ICB Bearing Fan, Black
365,00 AED
- Supports 12V-2×6 PCIe connector with ATX 3.1 and PCIe Gen 5 standard
- Latest PCIe Gen 5 standard to support up to 2X power excursion
- Silent running 120mm ICB cooling fan
- Black embossed cable design
- Main Japanese electrolytic capacitors
- High efficiency with Cybenetics Gold certification
- 24/7 continuous power output with 40℃ operating temperature
- Compact design with a 140mm depth for easy integration
| Product No. | SST-TR750R-GF |
| Model (safety certification) | SST-AX0750FCGD-A |
| Color | Black (lead-free paint) |
| Max. DC Output | 750W |
| Power Density | 415.3W/L |
| Load Range (Output) | |
| +3.3V | Max: 18A / Min: 0A / Range: ±5% / Line Reg.: ±1% / Ripple: 50mV |
| +5V | Max: 18A / Min: 0A / Range: ±5% / Line Reg.: ±1% / Ripple: 50mV |
| +12V1 | Max: 62.5A / Min: 0A / Range: ±5% / Line Reg.: ±1% / Ripple: 120mV |
| +5VSB | Max: 3.0A / Min: 0A / Range: ±5% / Line Reg.: ±1% / Ripple: 50mV |
| -12V | Max: 0.3A / Min: 0A / Range: ±10% / Line Reg.: ±1% / Ripple: 120mV |
| Combined +3.3V & +5V | 100W |
| Combined +12V | 750W |
| Input Voltage | 90 ~ 264 Vrms |
| Input Frequency Range | 47Hz ~ 63Hz |
| PFC | Active PFC (PF > 0.9 at full load) |
| Efficiency | 87% ~ 89% overall |
| MTBF | 100,000 hours |
| Operating Temperature | 0°C ~ 40°C |
| Protection | Over power, Over current, Over voltage, Short circuit, Under voltage, Over temperature |
| Connectors | 1 x 24/20-Pin motherboard 2 x 8/4-Pin EPS/ATX 12V 1 x 12+4-Pin 12V-2x6 3 x 8/6-Pin PCIe 6 x SATA 2 x 4-Pin Peripheral |
| Cooling System | Single 120mm ICB bearing fan |
| Noise Level | 18 dBA min. |
| Certification | Cybenetics Gold |
| Form Factor | ATX (PS2) |
| Dimension (W x H x D) | 150mm x 86mm x 140mm / 5.91" x 3.39" x 5.51" |
| Weight | 1.56 kg |
