Sharkoon REBEL P30 Gold ATX 3.0 Full Modular Power Supply Unit, 1000W Power, 80 PLUS Gold Efficiency, LLC + DC/DC, 135mm FDB Fan, PCIe Gen5, HQ Japanese Capacitors, White
911.00 AED
| 80 PLUS Certification | 80 PLUS Gold |
| Form Factor | ATX 3.0 |
| Continuous Power | 1,000 W |
| ErP Compatible | ✓ |
| Technology | LLC + DC/DC |
| Japanese Primary Capacitors | ✓ |
| All Japanese Capacitors | ✓ |
| MTBF | Minimum 100,000 hours |
| Operating Temperature | 0°C - 50°C |
| Standby Power | < 0.5 W |
| Weight without Cables | 1.7 kg |
| Dimensions (L x W x H) | 150 x 160 x 86 mm |
| Frame Color | Black |
| Input | |
| Voltage | 100 - 240 VAC |
| Frequency | 50 - 60 Hz |
| Input Current (110/230 V) | 12A / 6A |
| Output | |
| 12 V Rail(s) | 1 |
| Load 3.3 V | 24 A |
| Load 5 V | 24 A |
| Max. Combined Power 3.3 V + 5 V | 120 W |
| Load 12 V1 | 83.3 A |
| Max. Combined Power 12 V | 1,000 W |
| Load 5 VSB | 3 A |
| Load -12 V | 0.5 A |
| 12VHPWR Load | 600 W |
| Cable and Connectors | |
| Cable Configuration | Fully Modular |
| Flat Cables | ✓ |
| Maximum Cable Length | 100 cm |
| Length of Motherboard Connector | 62 cm |
| Length of CPU Connector | 73 cm |
| Length of 12VHPWR Connector | 62 cm |
| Length of PCIe Connector | 55 cm + 15 cm |
| Cable Length to First Peripheral | 55 cm |
| 20+4-Pin Motherboard Connector | 1 |
| 4+4-Pin CPU Connector | 1 |
| 8-Pin CPU Connector | 1 |
| PCIe 6+2-Pin Connector | 4 |
| 12VHPWR Connector | 1 |
| SATA Connector | 12 |
| IDE Connector | 2 (via Adapter) |
| Floppy Connector | 1 (via Adapter) |
| Fan | |
| Fan Size | 135 mm |
| Type | Fluid Dynamic Bearing |
| Protections | |
| OCP (Overcurrent Protection) | ✓ |
| OVP (Overvoltage Protection) | ✓ |
| UVP (Under Voltage Protection) | ✓ |
| SCP (Short Circuit Protection) | ✓ |
| OTP (High Temperature Protection) | ✓ |
| OPP (Over Power Protection) | ✓ |
| Security Certificates | |
| EC | ✓ |
| FCC | ✓ |
| UKCA | ✓ |
| CB | ✓ |
