Lian-Li EDGE GOLD Fully Modular Power Supply, 1000W Power, 80 PLUS Gold Efficiency, 120mm FDB Fan Type, Active PFC, ATX 3.1 Form Factor, 2400 RPM Fan Speed, Black

559,00 AED

Send Enquiry On Whatsapp
Add to Enquiry
  • L-shape design tailored for dual chamber cases
  • 80 PLUS Gold efficiency
  • PCIe 5.1 ready with in-house R&D 12V-2×6 alloy copper soldered terminals
  • Detachable USB hub with 4 internal USB 2.0 headers and 6 PWM headers
  • Removable magnetic fan dust filter
  • Built with German top-end, industrial-grade EPCOS capacitors
  • Fully modular braided-texture cables with pre-installed cable combs on MB/CPU/GPU connectors
Model EG1000G
Dimensions 182mm (D) x 86mm (W) x 150mm (H)
Design Fully modular
Color Black / White
Material Steel
Form Factor ATX 3.1
Certification 80 PLUS GOLD / Cybenetics GOLD / PPLP GOLD
Max DC Output 1000W
+3.3V & +5V Combined 120W
+12V Combined 996W
Input Voltage 100-240Vac
Frequency / Current 12-6A 50-60Hz
PFC Active PFC (PF > 0.90)
Efficiency (Max) 91.24%
Protection OCP / OVP / OTP / OPP / SCP / UVP
Fan Type 120mm FDB
Fan Speed 2400RPM
Noise Level 39.3dBA
Connectors 1 x 24/20-Pin motherboard connector (620mm) x1pcs
1 x 8/4+4 Pin CPU/ATX 12V connector (750mm) x1pcs
1 x 4+4 Pin CPU/ATX 12V connector (750mm) x1pcs
1 x 6+2 Pin PCle connector (650mm + 100mm) x1pcs
4 x SATA connector (300mm-15mm-15mm-15mm) x 1pcs
4 x Y Type SATA connector (375mm-150mm-150mm-150mm) x1pcs
4 x SATA connector (400mm-150mm-150mm-150mm) x 1pcs
4 x 4-Pin Peripheral connector (500mm-150mm-150mm- 150mm) x1pcs
1 x 12V – 2X6 600W connector (650mm) x1pcs
USB*9pin – USB*9pin connector (470mm) × 1pcs
USB*9pin -Type A connector (550mm) × 1pcs
